README
PHP 的 Slack Block Kit
👉 通过 OOP 接口使用 Slack Block Kit 语法格式化消息和模态 👈
由 Jeremy Lindblom (@jeremeamia) 提供
简介
来自 Slack 的 Block Kit 文档
Block Kit 是 Slack 应用程序的 UI 框架,在构建消息和其他 表面 的体验时提供了控制与灵活性的平衡。
通过组合、更新、排序和堆叠 块(几乎在 Slack 的任何地方都可用),自定义信息和引导用户了解您应用程序的功能,以定制信息的顺序和外观。
此库为使用 Slack Block Kit 编写消息/模态提供了 PHP 的 OOP 接口。它还可以反向操作,这意味着您可以将消息/模态 JSON 填充到对象层次结构中。
Block Kit 概念
此库帮助您在代码中以编程和动态方式构建 Slack 消息和模态,但您首先需要了解它们的一般工作原理。库试图防止您在 Block Kit 中执行不被允许的操作,但可能不会针对每个单独的条件进行验证。
您可能需要查看 Slack 文档中的以下概念
- 表面 - 有 3 种主要类型:消息、模态和应用首页
- 块 - 包括 部分、上下文、操作 等
- 块元素 - 包括按钮、菜单、文本输入和其他交互式组件。我们在这个库中将所有这些称为“元素”。
- 组合对象 - 我们在库中称之为“部分”
通常,我们将 Block Kit 中的所有这些不同事物统称为“组件”。
安装
通过 Composer 轻松安装
composer require slack-php/slack-block-kit
然后在项目初始化代码中包含 Composer 生成的自动加载器。
注意:此库是为 PHP 8.1+ 构建的。
基本用法
此库支持使用 PHP 8 的命名参数功能进行直观的语法来组合 Slack 表面(例如,消息、模态)。
<?php use SlackPhp\BlockKit\Surfaces\Message; use SlackPhp\BlockKit\Blocks\Section; use SlackPhp\BlockKit\Blocks\Divider; use SlackPhp\BlockKit\Blocks\BlockImage; // ... // CONSTRUCTION $msg = new Message( ephemeral: true, blocks: [ new Section('Don\'t you just love XKCD?'), new Divider(), new BlockImage( title: 'Team Chat', imageUrl: 'https://imgs.xkcd.com/comics/team_chat.png', altText: 'Comic about the stubbornness of some people switching chat clients', ), ] ); // VALIDATION // Throws a ValidationException if any of the components are invalid or missing required properties. $msg->validate(); // OUTPUT // To convert to JSON (e.g., to send to Slack API, webhook, or response_url), use PHP's `json_encode()` function. echo json_encode($msg); // OR you can use the surfaces's `toJson()` method, which also includes a convenience parameter for pretty printing. echo $msg->toJson(true); // OR you can just convert to an array and do something else with the data. print_r($msg->toArray());
Kit 门面
Kit
类充当整个库组件集的门面,并为每个组件提供工厂方法。它允许您减少在构建消息(或其他表面)时需要导入的类数量。
每个工厂方法具有与原始组件构造函数相同的参数。
<?php use SlackPhp\BlockKit\Kit; // ... $msg = Kit::message( ephemeral: true, blocks: [ Kit::section('Don\'t you just love XKCD?'), Kit::divider(), Kit::blockImage( title: 'Team Chat', imageUrl: 'https://imgs.xkcd.com/comics/team_chat.png', altText: 'Comic about the stubbornness of some people switching chat clients', ), ] );
流畅接口
如果命名参数不适合您,还有另一种方法可以设置组件的属性,即通过设置器方法。每个组件都有可链式设置的属性设置器方法,这允许实现流畅风格的接口。
$msg = Kit::message() ->ephemeral() ->blocks( Kit::section('Don\'t you just love XKCD?'), Kit::divider(), Kit::blockImage() ->title('Team Chat') ->imageUrl('https://imgs.xkcd.com/comics/team_chat.png') ->altText('Comic about the stubbornness of some people switching chat clients') ), );
流式语法不依赖于 Kit
外观。组件类有一个静态的 new()
方法,也可以用于链式调用。
$msg = Message::new() ->ephemeral() ->blocks( Section::new('Don\'t you just love XKCD?'), Divider::new(), BlockImage::new() ->title('Team Chat') ->imageUrl('https://imgs.xkcd.com/comics/team_chat.png') ->altText('Comic about the stubbornness of some people switching chat clients') ), );
空值
所有属性在设置之前都视为空/空值。
您还可以显式地将属性设置为空,以移除其值(例如,从您从现有数据创建的组件中)。
$section->accessory(null);
最后,列表中的块、元素、选项等允许空值,因此可以使用条件项目。
$msg = Kit::message( blocks: [ Kit::section('Don\'t you just love XKCD?'), ($includeDivider) ? Kit::divider() : null, Kit::blockImage( title: 'Team Chat', imageUrl: 'https://imgs.xkcd.com/comics/team_chat.png', altText: 'Comic about the stubbornness of some people switching chat clients', ), ] );
在块套件构建器中预览
Slack 提供了一个 交互式块套件构建器,用于编写/测试消息和其他界面。这是探索和了解块套件格式的绝佳方式。
Kit::preview
方法允许您将消息/界面作为块套件构建器 URL 渲染,这样您就可以通过它们的交互式工具在浏览器中链接到预览或消息/界面。这将帮助您了解它在 Slack 客户端中的渲染效果。
$msg = Kit::message( ephemeral: true, blocks: [ Kit::section('Don\'t you just love XKCD?'), Kit::divider(), Kit::blockImage( title: 'Team Chat', imageUrl: 'https://imgs.xkcd.com/comics/team_chat.png', altText: 'Comic about the stubbornness of some people switching chat clients', ), ] ); echo Kit::preview($msg);
输出
https://app.slack.com/block-kit-builder#%7B"blocks":%5B%7B"type":"section"%2C"text":%7B"type":"mrkdwn"%2C"text":"Don%27t%20you%20just%20love%20XKCD%3F"%7D%7D%2C%7B"type":"divider"%7D%2C%7B"type":"image"%2C"title":%7B"type":"plain_text"%2C"text":"Team%20Chat"%7D%2C"image_url":"https:%5C%2F%5C%2Fimgs.xkcd.com%5C%2Fcomics%5C%2Fteam_chat.png"%2C"alt_text":"Comic%20about%20the%20stubbornness%20of%20some%20people%20switching%20chat%20clients"%7D%5D%7D
这里是实际的块套件构建器链接。
它在块套件构建器中看起来可能像这样
组件活化
某些 Slack 应用程序集成(如与模态集成)需要接收现有界面的 JSON,然后修改或替换该界面。您可以使用其 fromArray
方法(或 fromJson
)将界面的 JSON(或元素)"活化"为其对象表示。
$messageJson = <<<JSON { "blocks": [ { "type": "section", "block_id": "block1", "text": { "type": "mrkdwn", "text": "*foo bar*" } } } } JSON; // Use fromArray to hydrate the message from parsed JSON data. $decodedMessageJson = json_decode($messageJson, true); $message = Message::fromArray($decodedMessageJson); // OR... use fromJson to hydrate from a JSON string. $message = Message::fromJson($messageJson);
消息格式化
存在 Md
类,用于提供格式化 "mrkdwn" 文本的辅助工具。这些辅助工具可以用于避免记住 Slack mrkdwn 语法。此外,如果需要,这些函数将自动正确转义 <
、>
和 &
字符。
示例
// Note: $event is meant to represent some kind of DTO from your own application. $md = Kit::md(); $msg = Kit::message( blocks: [ Kit::section( text: $md->sub( 'Hello, {audience}! On {date}, {host} will be hosting an AMA in the {channel} channel at {time}.', [ 'audience' => $md->atHere(), 'date' => $md->date($event->timestamp), 'host' => $md->user($event->hostId), 'channel' => $md->channel($event->channelId), 'time' => $md->time($event->timestamp), ] ) ) ] );
示例结果
{ "blocks": [ { "type": "section", "text": { "type": "mrkdwn", "text": "Hello, <!here>! On <!date^1608322949^{date}|2020-12-18T20:22:29+00:00>, <@U12345678> will be hosting an AMA in the <#C12345678> channel at <!date^1608322949^{time}|2020-12-18T20:22:29+00:00>." } } ] }
虚拟块
除了标准块之外,以下是一些由一个或多个其他块组成的虚拟/自定义块
TwoColumnTable
- 使用带有字段的分区来创建具有可选标题的两列表格。CodeBlock
- 使用分区来创建具有可选标题的代码块。
类结构
Surface
、Block
、Element
和Part
都是块套件Component
的类型。- 可以使用
Kit
外观作为工厂创建任何Component
。 Component
包含定义其外观和行为的属性和子Component
。Part
是构成其他Component
属性的重复模式。Surface
包含一个或多个Block
。Block
包含一个或多个Element
。- 大多数
Element
以某种方式是交互式的。 - 许多
Element
也是Input
,接收用户输入。
请参阅 YUML
[Kit]-creates>[Component] [Surface]^[Message] [Surface]^[Modal] [Surface]^[AppHome] [Surface]^[Attachment] [Component]^[Surface] [Component]^[Block] [Component]^[Element] [Component]^[Part] [Component]<>->[Part] [Surface]<>->[Block] [Message]<>->[Attachment] [Block]<>->[Element] [Element]^[Input] [Element]-[note:Examples: Button, OverflowMenu {bg:cornsilk}] [Input]-[note:Examples: Select Menu, DatePicker {bg:cornsilk}] [Part]-[note: Examples: Text, Fields {bg:cornsilk}] [Block]-[note: Examples: Section, Actions {bg:cornsilk}]
贡献
欢迎贡献以支持新元素、添加测试、改进代码等。
